The 12V 9mm DIP Single Colour Pixel LED is a compact and reliable lighting solution for signage and architectural décor. Each pixel consists of a high-brightness 9 mm DIP LED encapsulated in a clear waterproof housing and connected through 7-inch (≈18 cm) PVC-insulated wires, providing extra flexibility for installation spacing and layout design.
Operating on 12 V DC, this LED module ensures low-power consumption, long lifespan, and consistent illumination across each pixel. The extended 7-inch lead makes wiring easier in large decorative projects such as building outlines, ceilings, gumbads (domes), and LED art installations.
Key Features & Specifications
| Feature | Details |
|---|---|
| Operating Voltage | 12 V DC |
| LED Type | 9 mm DIP LED |
| Colour | Single Colour (Red, Green, Blue, White, etc.) |
| Connection Type | Series / Daisy-Chain Ready |
| Wire Type | Flexible PVC-Insulated Copper Wire |
| Wire Length | 7 inches (≈18 cm) |
| Material | Clear PVC Lens + Durable Plastic Body |
| Mounting | Push-Fit into 9 mm Drilled Holes |
| Power Consumption | ~0.24 W per LED (varies by colour) |
| Waterproof Rating | IP65 / Suitable for Outdoor Use |
| Operating Temperature | –20 °C to +60 °C |
| Lifespan | >30,000 Hours |
| Control Type | Static Single Colour (No Data Line Required) |
| Applications | Signage, Domes, Building Outlines, Road Ceilings, Decorative Lighting
|
